Mini heat pump

The compact solution with simple operation and convincing performance

€599.00 Prices incl. VAT

Available, delivery time: 1-4 days

The shipping costs are € 10,- for international shipping.

Orders over € 200, - have free delivery, unless otherwise stated in the checkout. Delivery will be made within 3 - 4 business days after sending the order confirmation.

We want you to be completely satisfied with the purchase of your BWT product. If you are not, we will refund the full purchase price.

To do this, please let us know the reason for your dissatisfaction via the contact form and provide us with your contact details. For further processing, we will then contact you personally as soon as possible.

Pay conveniently with credit card, online banking, PayPal, Klarna, Apple Pay or other available payment methods.

Inform me when the product is available as a special offer.

I agree to the BWT privacy policy

PRACTICAL & COMPACT: Small heat pump with small footprint, user-friendly and easy operation, simply connects to the house power
HEATING PERFORMANCE: Max. Heat output 3.5 kW, ideal for above ground pools and spas between 2 and 15 m³
HIGH QUALITY COOLANT: Environmentally friendly & efficient R32 coolant

Description

The mini heat pump from BWT is ideal for heating smaller above-ground pools with a water content of up to 15 m³. The heat pump is particularly compact and easy to operate. This allows the pool water to be tempered as desired and the bathing season to be extended.

Installation and commissioning

Installation is completed in just a few minutes - the mini heat pump is supplied ready to plug in and can be connected directly to the house electricity. On the water side, the heat pump is simply mounted between the sand filter system and the inlet nozzle.

Once it has been successfully installed, the heat pump can go straight into operation. Operation is intuitive and particularly easy to understand. The desired temperature can be easily set via the display after switching on the heat pump. The pump then starts to heat the pool.

Technical details

Product number: 125500854

App control:	No
COP at 100 % of nominal power (at 15 °C air and 26 °C water):	4,1
COP at 100 % of nominal power (at 26 °C air and 26 °C water):	5,5
Connection:	32
Coolant:	R 32
Dimensions in mm (w x h x d):	310 x 357 x 375 mm, 412 x 367 x 425 mm
Heating capacity in kW (15 °C air & 26 °C water):	2.4
Heating capacity in kW (26 °C air & 26 °C water):	3.5
Housing:	Metal
Inverter technology:	No
Modes:	On/Off
Operating temperature:	10 - 43 °C
Power supply:	220 - 240 V / 1ph / 50Hz
Pump connections:	32 - 38 mm
Recommended flow rate:	1.5 - 2 m³/h
Recommended swimming pool volume:	2 - 15 m³
Thermal electrical protection:	5 A
Type of heat exchanger:	Helical titanium heat exchanger
Weight:	24 kg
